MKET-T: Electric steam mixer kettle, tilting
50 PSI STEAM JACKETED MIXER KETTLE (3.5 Bar boiling Pan), 2/3 STEAM JACKETED, HIGH SPEED COOKING, (12 & 20 GALLONS, 45 & 80 LITERS)
CLEVELAND, Model MKET-12-T & MKET-20, Table Type Tilting, 12 & 20 Gallon, Electric Mixer Kettle with permanently filled steam jacket, 50 psi jacket rating and safety valve, Solid State Temperature (±1°F) and Low Water Safety Controls, rear mounted Combination Pressure/Vacuum Gauge, infinitely variable speed, 3/4 H.P. Timing Belt Drive, bayonet mounted Agitator and Scraper with removable blades, safety device prevents high speed starts, mixing stops when bridge is lifted. Kettle and all exterior surfaces are Stainless Steel.
|
Rolled Rim
Re-inforced rolled rim design prevents damage to kettle rim, eliminates "bar rim designs" |
|
Heating Elements
Welded-in heating elements, (holds vacuum better, won't leak or loose water) |
|
Easily Cleaned
Kettle and all exterior surfaces are of type 304 stainless steel with an #4 finish |
|
Water Level Control
Solid state water level control (no sight glass gauge to break or leak) |
|
Element Cover
Splash proof element cover with a double gasket seal |
| Large Pouring Lip |
|
Standard Voltage
120/208-240 volts, 60 Hz, 3 phase, 4 wire |
|
Mixing
Infinitely variable speed for all conditions; scraper from 0-70 rpm, agitator from 0-210 rpm. Removable (without tools) Nylon Blades scrape entire jacketed surface. 3/4 horse power D.C. Timing Belt Drive. Safety Device prevents High Speed Starts. Mixing stops when bridge is lifted. Agitator and Scraper are bayonet mounted for easy removal. Enclosed, balanced, 10 Gauge Stainless Steel Mixer Bridge. Gallon Markers on Scraper Shaft. |
| No Water Gauge required |
|
Rear Mounted
Pressure/Vacuum Gauge and Pressure Relief Valve. |
|
Solid State Temperature Control
Accurate, consistant solid state temperature controls (mechanical thermostat not as accurate) - less than ±1°C variance (ideal for simmering). Operating temperature range from 145° - 260°F (63°C - 127°C) Control panel includes: LED indicator for heat cycle, LED indicator for low water Power ON/OFF switch, Adjustable temperature control dial. |
|
Solid State
Low Water Safety Control. |
|
Steam Jacket
50 PSI (3.5 Bar) Steam Jacket Rating for faster cooking. Steam jacket filled with treated water, venting and/or refilling is not required. |
316 Kettle Liner316 Stainless Steel kettle liner for high acid food products (316-G) |
|
Cover(MTP) |
|
ElectricalHigh wattages (HW) and special voltages |
|
Equipment StandStainless Steel equipment stand with drain drawer and splash shield (ST-28) |
|
Flow Diverter(FD) |
|
Food Strainers(FS) |
|
Kettle Accessory Kit (KAK) includes:Clean-up Brush (CB), 36" Kettle Paddle (KP), 36" Kettle Whip (KW), 36" Kettle Brush (KB), Draw-off Brush (DB), 24 oz. Ladle (KL) |
|
Water Meter(GMF or LMF) Wall Mounted or on Stand (SWM) |
|
Faucet (standard on MKET-20-T)Hot and cold (DPK) or cold only (SPK) water faucet with swing spout. Requires mounting bracket (FBKT) |
